2MP Hikvision CCTV Camera DS-2CE56D8T-IT3E 2.8mm Fixed Lens 40m IR POC Turret

CCTV Camera Hikvision 2MP 2.8mm Fixed Lens 40m IR POC Turret Camera, DS-2CE56D8T-IT3E Image Sensor 2-megapixel progressive scan CMOS, Illumination Colour: 0.005 Lux @ (F1.2, AGC ON), 0 Lux with IR, Clear imaging even against strong backlighting due to 130 dB true WDR technology.

The Benefits of Hikvision CCTV Camera DS-2CE56D8T-IT3E

• 2 MP high performance turret camera
• Strong night performance, capturing images in ultra-low light down to 0.003 lux
• Clear imaging output despite strong back lighting due to 130 dB true WDR technology
• 3D DNR technology delivers clean and sharp images and Adopts HD-TVI technology
• Smart IR with advanced infrared technology and 60 m IR distance: EXIR 2.0
• Water and dust resistant (IP67)
• Transmits both HD video and power over the same coaxial cable
• Up to 40m IR distance

Camera

• Image Sensor :2 megapixel progressive scan CMOS
• Resolution : 1920 (H) × 1080 (V)
• Illumination Color: 0.005 Lux @ (F1.2, AGC ON), 0 Lux with IR
• Shutter Time PAL: 1/25 s to 1/50, 000 s, NTSC: 1/30 s to 1/50, 000 s
• Day & Night IR cut filter
• Angle Adjustment Pan: 0° to 360°, Tilt:0° to 75°, Rotate: 0° to 360°
• Signal System PAL/NTSC
• Slow Shutter : 16 times

Lens

• Lens Type 8 mm, 3.6 mm, 6 mm, 8mm, 12mm fixed focal lens
• Focal Length & FOV 5° (2.8 mm), 82.6° (3.6 mm), 54.4° (6 mm), 38° (8 mm), 24.4° (12 mm)
• Lens Mount M12


• Image Settings Brightness, Sharpness, Mirror, Smart IR
• Frame Rate PAL: 1080p@25fps,NTSC: 1080p@30fps
• Day/Night Mode Auto/Color/BW (Black and White)
• Wide Dynamic Range (WDR) > 120 dB
• Image Enhancement WDR/BLC/OFF
• Privacy Mask ON/OFF, 4 programmable privacy masks
• Noise Reduction Level 1 to 10
• White Balance ATW/MANUAL
• AGC Support

Interface

• Video Output TVI Default

Event

• Motion Detection 4 programmable motion areas

General

• Material of Metal & Plastic
• Dimension Φ 110 mm × 93.2 mm (Φ 4.33″ × 3.67″)
• 350 g (0.77 lb.)
• Operating Condition -40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensation)
• Communication Up the coax, Protocol: HIKVISION-C (TVI output)
• Language English, Chinese
• Power Supply 12 VDC ±25%/PoC.af
• Consumption 3.6 W
• IR Range Up to 60 m
• Approval
• Protection IP67

Compliant with the IP67 standard, you don’t have to worry about dust or water damage to your camera. Combined with an all-aluminium body, these cameras last long. The device can be dropped into the water up to a depth of 1 meter for 30 minutes without damage.
